Gonsin Conference Room Interpretation Systems Translation Equipment

1 / 5

Gonsin Conference Room Interpretation Systems Translation Equipment

Customization:	Available
Color:	Black
Type:	Voice Conferencing System

Send Inquiry

Product Description

📋 Basic Information

Model NO.DCS-3021-W+TC-FSJ04B/08B/12B/16B

Modulation ModeFs-Fhss Technology

Frequency Range2.4-2.5GHz

Encryption MethodAES

System Max CapacityUnlimited Receivers

Grouping Functionup to 255 Groups

Sensitivity-121dBm

Earphone Jack3.5mm Jack Stereo

OLED Screen35*10mm

Battery Service Time16 Hours

CommunicationWireless

OriginChina

🎙️ FS-FHSS Wireless Simultaneous Interpretation System

The FS-FHSS wireless simultaneous interpretation system utilizes digital wireless communication and innovated FS-FHSS (Frequency Selecting - Frequency Hopping Spread Spectrum) technology. It comes with super-strong anti-interference capability and broad bandwidth, provides perfect CD-level audio quality, and utilizes AES technique to encrypt data. Effective communication distance is 50~500m. Signals can be transmitted out in all directions. Eight channels are configured with one antenna unit, which reduces deployment difficulty and saves system investment. The system is able to modulate and transmit up to 16 channels at the same time, allowing participants to select a channel to hear the required language.

What is FS-FHSS Technology?

Frequency hopping communication technology is a common spread spectrum communication technology widely applied to various wireless communication fields. The unique FS-FHSS technology can monitor and select the undisturbed frequency band, ensuring the stability of communication for discussion, simultaneous interpretation, and voting functions.

🌟 System Features

Innovated FS-FHSS Technology
Highly flexible for indoor/outdoor/temporary venues
AES data encryption for security
Immune to light interference and signal jammers
Adjustable power (50m to 500m range)
Unlimited receiver capacity within scope
All-direction signal transmission
Supports up to 16 interpretation channels
Simple deployment with single access point

🎧 Wireless Simultaneous Interpretation Receiver

Models: TC-FSJ04B/08B/12B/16B

CD-level sound quality
OLED display for signal and battery status
Real-time battery level & low power alarm
255 Groups available with no interference
Unified shut-down function
16-hour consecutive battery life
Automatic power-off when no signal/earphone
Centralized charging (60 units per case)

⚙️ Technical Parameters

Modulation mode	FS-FHSS technology
Frequency range	2.4-2.5GHz
Encryption method	AES
System Max capacity	Unlimited receivers within signal distance
Grouping function	up to 255 groups
Sensitivity	-121dBm
Earphone jack	3.5mm jack stereo
OLED screen	35×10mm
Battery	Lithium battery/ 2 AA batteries
Battery service time	16 hours
Dimension (L×W×H)	136×50×21mm
Working temperature	0~45°C

Frequently Asked Questions

What is the effective range of the wireless system?

The transmission power is adjustable, and the effective communication distance can reach from 50m to 500m depending on the setting and environment.

How many languages can be interpreted simultaneously?

The system supports up to 16 channels in total (typically 1 floor language and 15 interpretation audio channels).

Is the wireless signal secure from eavesdropping?

Yes, the system utilizes AES encryption technology to protect data and prevent malicious interference or unauthorized listening.

How many receivers can one system support?

The system capacity is unlimited within the effective signal coverage area, making it suitable for any conference size.

What kind of batteries do the receivers use?

The receivers are highly flexible and can be powered by either a rechargeable lithium battery or 2 standard AA batteries.

Does the system work in outdoor environments?

Yes, the FS-FHSS technology is immune to light sources and provides super-strong anti-interference, making it perfect for both indoor and outdoor venues.
